How can I export my Data?

How can I export my Data?




The Probewell Connect application offers two data exports formats for XT series test reports: PDF and CSV.

In both cases, test data is extracted from the XT tester’s non-volatile memory and saved on a local drive on a Windows computer.

The PDF report format is a human readable, non-modifiable representation of the test data.

PDF Include all the graphic representation available on the app.

The CSV report format shows the test data in a row-column text file that can be viewed with a basic text editor or Microsoft Excel.


Export all test reports to CSV

  1. Power up the XT series tester.
  2. On a PC, runing under Windows 10, connect to the XT series tester’s wireless network. Complete procedure on how to do this is outlined in the section Connecting to the XT series tester of this document.
  3. Start the Probewell Connect application.
  4. Go to the Records tab.
  5. Click on the Export all to CSV button. All test reports present on the XT tester’s memory are exported to the CSV report file path (configurable in the Local Preferences tab). Each individual test report is saved to a single CSV file and a new folder is created for each test group.

Export a test group to CSV

  1. Power up the XT series tester.
  2. On a PC, runing under Windows 10, connect to the XT series tester’s wireless network. Complete procedure on how to do this is outlined in section Connecting to the XT series tester of this document.
  3. Start the Probewell Connect application.
  4. Go to the Records tab.
  5. Enter the test group by pressing on its entry in the list.
  6. Click on the Export group to CSV button. When prompted, select a folder to save the tests.
All test reports present on the XT tester’s memory are exported to the selected path. Each individual test report is saved to a single CSV file in that folder.

Export a single test to CSV or PDF

  1. Power up the XT series tester.
  2. On a PC, runing under Windows 10, connect to the XT series tester’s wireless network. Complete procedure on how to do this is outlined in section Connecting to the XT series tester of this document.
  3. Start the Probewell Connect application.
  4. Go to the Records tab.
  5. Enter the test group by pressing on its entry in the list.
  6. Enter the test report by pressing on its entry in the list.
  7. Click on the Export to CSV or Export to PDF button. When prompted, select a folder to save the test. The default file name includes the device serial number, the test ID and test date and is meant to be unique.

Sample Reports:
